Transistor 2SC4916

Transistor 2SC4916

NPN Saida horizontal 1500/600v 7A 50w c/diodo

VCBO Collector-base voltage Open emitter 1500 V
VCEO Collector-emitter voltage Open base 600 V
VEBO Emitter-base voltage Open collector 5 V
IC Collector current 7 A
ICM Collector current-Peak 14 A
IB Base current 3.5 A
PC Collector power dissipation TC=25 50 W
Tj Junction temperature 150
Tstg Storage temperature -55~150
